ThinkPad OneLink 40A4 Dockign Station With 90w Adapter Included 45N0481
Technical Information
Ports and Security
(4) USB 3.0 (one provides always-on mobile device charging)
(2) USB 2.0
(1) OneLink+ upstream connector
(2) DisplayPort
(1) VGA
(1) Gigabit Ethernet
(1) Stereo/Mic Combo Port
(1) Kensington Lock Slot
(1) DC in
Recources from Lenovo
Overview
Drivers and Downloads
Documentaions and Manuals
|
Display Configuration | DisplayPort | DisplayPort | VGA |
|---|---|---|---|
| One Display | 3840x2160@60Hz | - | - |
| - | - | 1920*1200@60Hz | |
| Two Displays | 3840x2160@60Hz | 1024*768@60Hz | - |
| 3840x2160@30Hz | 3840x2160@30Hz | - | |
| 3840x2160@60Hz | - | 1024*768@60Hz | |
| 3840x2160@30Hz | - | 1920*1200@60Hz | |
| Three Displays | 3840x2160@30Hz | 3840x2160@30Hz | 1024*768@60Hz |
| 1920*1200@60Hz | 1920*1200@60Hz | 1920*1200@60Hz |
Physical Specifications
Compatibility
Please see compatibility tab for supported models.
