573400-001 - AMD VIOLET6-GL8E Pegatron Motherboard / System Board
| Chipset | NVIDIA GeForce 9100 |
| FSB | 5200MT/s (5.2 GT/s) |
| Processor Support | AM3 processors only |
| AMD Phenom II X4 9xx/9xxe/8xx Quad-Core (Deneb) | |
| AMD Phenom II X3 7xx/7xxe Triple-Core (Heka) | |
| AMD Phenom II X2 5xx (Callisto) | |
| AMD Athlon II X4 6xx/6xxe (Propus) | |
| AMD Athlon II X3 4xx/4xxe (Rana) | |
| AMD Athlon II X2 2xx/2xxe (Regor) | |
| Memory Support | PC3-10600 (DDR3-1333), PC3-8500 (DDR3-1066) |
| Supports 4GB DDR3 DIMMs | |
| Supports up to 16 GB on 64-bit PCs | |
| Supports up to 4 GB on 32-bit PCs | |
| Back I/O Ports | S/PDIF coaxial out |
| Video Graphics Adapter | |
| IEEE 1394 | |
| RJ-45 Network (LAN) | |
| Audio: Center/Subwoofer (yellow orange) | |
| Audio: Rear Speaker Out (black) | |
| Audio: Line In (gray) | |
| Audio: Line Out (light blue) | |
| Audio: Microphone (lime) | |
| Audio: Side Speaker Out (pink) | |
| 4x USB 2.0 | |
| DVI | |
| Compatible Models | HP Pavilion Elite: M9837CH M9840SC M9844SC M9860SC Slimline: S5213DE S5222FR S5224FR S5229UK S5260F S5350Z S5360F S5361F S5350Z Pavilion: A4302F A4308F A4316F A4316F-B P6202DE P6204ES P6214IT P6226IT P6239DE P6240NL P6241AT P6245AT P6245SC P6255KR P6262DE P6303AT P6305AT P6306IT P6310DE P6310F P6310SC P6310Y P6311DE P6311F P6313W P6314IT P6315DE P6318F P6320F P6320PT P6320Y P6325SC P6328DE P6330DE P6341FR P6341SC P6342FR P6355KR P6357FR P6359FR P6360FR P6362FR P6365FR P6366FR P6373FR P6374FR P6375IT P6390DE P6404Y |
